EPS Sandwich Wall Panel Prefabricated Steel Building

Productivity:
100000 Square Meter/Square Met
Place of Origin:
Hangzhou Zhejiang, China (Mainland)
Supply Ability:
100000 Square Meter/Square Meters / Month
Certificate:
ISO
  • Mr. Catherine Zhou

Product Description

Type: H-Section Steel Trademark: Special Purpose Steel, PTH Connection Form: Bolt Connection Type of Steel For Building Structure: High-Strength Steel Residential Wall Structure: Wallboard Certification: ISO Downspout: PVC Pipes Wall Panel: Steel Sheet or Sandwich Panel Material: Steel Structure, Sandwich Panel Size: Designed as Per Customer′s Requirement Origin: Hangzhou Zhejiang, China (Mainland) Standard: GB, ISO Forming: Hot-Rolled Steel Member: Steel Column Carbon Structural Steel: Q235 Application: Steel Workshop, Steel Structure Platform, Steel Fabricated House, Structural Roofing Eaves Gutter: PVC Roof Insulation: Steel Sheet or Sandwich Panel Usage: Workshop; Warehouse; Hotel etc Main Structure: Steel Structure Plus Light Steel Keel Specification: CE; ISO9001: 2008 HS Code: 9406000090 EPS Sandwich Wall Panel Prefabricated Steel Building

1. For the wall and roof, you can have the following choice
A)Color Steel Sheet Wall, thickness 0.425mm, Galv. With painting on surface
Advantage: Low cost and easy to install, the volume for the whole warehouse will be small, it can save some containers to load
Disadvantage: Insulation is bad
B)Color Steel Sheet + Glass Fiber + Aluminium Paper
Advantage: The cost is reasonable, the volume for the whole warehouse will be small, it can save some containers to load
Disadvantage: Insulation is good, Installation will need more labor cost and hours
C) EPS Sandwich Wall Panel(50mm or 75mm, even 100mm for cold area)
Advantage: The cost is reasonable, Easy to Install, Insulation is reasonable
Disadvantage: The volume for the whole warehouse will be Big, it will need more containers to load
D)PU Sandwich Wall Panel(50mm or 75mm, even 100mm for cold area)
Advantage: Easy to Install, Insulation is the best, we have a special embossed PU wall panel(27mm), it can make the house looks very good
Disadvantage: The cost is high, the volume for the whole warehouse will be Big, it will need more containers to load
2. We can design the warehouse or workshop for you, but we need the following information.
A) The layout, it can be very simple, maybe just the length x width x height
B) The usage for the house, warehouse or workshop, is there some crane? If so, what's the capacity and qty.
C)Wind resistance and snow resistance
1. Opinions 1)We can supply all kinds of steel structures, Steel Building, metal building, modular house,     Steel Frame for warehouse, workshop, garage etc, steel beams, other riveting and welding parts.
2)We can also make and develop new parts according to customers' drawings and detailed dimensions.

2. Specifications



1)Size: MOQ is 100m2, width X length X eave height, roof slope
2)Type: Single slope, double slope, muti slope; Single span, double-span, Multi-span, single floor, double floors!
3) Base: Cement and steel foundation bolts
4)  Column and beam: Material Q345(S355JR)or Q235(S235JR) steel, all bolts connection! Straight cross-section or Variable cross-section!
5) Bracing: X-type or V-type or other type bracing made from angle, round pipe, etc
6) C or z purlin: Size from C120~C320, Z100~Z200
7) Roof and wall panel: Single colorfull corrugated steel sheet0.326~0.8mm thick, (1150mm wide), or sandwich panel with EPS, ROCK WOOL, PU etc insulation thickness around 50mm~100mm,
8)Accessories: Semi-transparent skylight belts, Ventilators, down pipe, Glavanized gutter, etc
9)Surface: Two lays of Anti-rust Painting!
10) Packing: Main steel frame without packing load in 40' OT, roof and wall panel load in 40' HQ!
3. Design Parameters If you need we design for you, pls supply us the following parameter together with detail size:
1)Live load on roof(KN/M2)
2)Wind speed(KM/H)
3)Snow load (KG/M2)
4)Earthquake load if have
5) Demands for doors and windows
6)Crane   (if have), Crane span, crane lift height, max lift capacity, max wheel pressure and min wheel pressure!

Contact us if you need more details on Steel Structure. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Steel Building、Steel Structure Building. If these products fail to match your need, please contact us and we would like to provide relevant information.
